TP-LINK OMADA ER706W | AX3000 GIGABIT VPN ROUTER
TP-LINK OMADA ER706W | AX3000 GIGABIT VPN ROUTER
Regular price
R 3,350.00 ZAR
Regular price
Sale price
R 3,350.00 ZAR
Taxes included.
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
TP-Link Omada ER706W | AX3000 Gigabit VPN Router
Flexible Wi-Fi Coverage through Business Wired Connectivity
FEATURES:
- AX3000 Dual-Band Wi-Fi - Supports 2,402Mbps on 5.0GHz and 574Mbps on 2.4GHz
- 6× Gigabit Ethernet Ports - 1× Gigabit SFP and 5× Gigabit RJ45 ports provide high-speed wired connectivity
- Omada Mesh Technology - Seamlessly connects to EAPs that support mesh technology, ideal for large-scale scenarios
- Centralised Management - Cloud access and Omada App for ultra convenience and easy management
- Boosted Coverage - Triple external antennas extend and concentrate the Wi-Fi signals
- High-Security VPN - Supports multiple VPN protocols including IPSec / SSL / Wireguard / PPTP / L2TP VPN, helping users to establish remote connections more flexibly
- Abundant Security Features - Advanced firewall policies, DoS defence, IP / MAC / URL filtering and more security functions protect your network and data
SPECIFICATIONS:
| SECURITY | |
| Access Control | Source/Destination IP Based Access Control |
| Filtering | Web Group Filtering |
| URL Filtering | |
| Web Security | |
| ARP Inspection | Sending GARP Packets |
| ARP Scanning | |
| IP-MAC Binding | |
| Attack Defence | TCP/UDP/ICMP Flood Defence |
| Block TCP Scan (Stealth FIN / Xmas / Null) | |
| Block Ping from WAN | |
| HARDWARE FEATURES | |
| Interface | 1× Gigabit SFP WAN/LAN Port |
| 1× Gigabit WAN Port | |
| 4× Gigabit LAN/WAN Ports | |
| 1× USB3.0 (Supports USB LTE Dongle and USB Storage) | |
| Button | Reset Button |
| Power Supply | 12VDC 2A Power Adapter |
| Wi-Fi Frequency and Signal Rate | 2.4GHz: 574Mbps |
| 5.0GHz: 2,402Mbps (HE160) | |
| Flash | 128MB NAND |
| DRAM | 512MB DDR4 |
| Dimensions (W × D × H) | 226 × 131 × 35mm (Antenna Dimensions Are Not Included) |
| Antenna | 2.4GHz: 2× 3dBi Dual-Band Detachable Antennas |
| 5.0GHz: 3× 4.5dBi Dual-Band Detachable Antennas | |
| Mounting | Desktop / Wall-mounting |
| Max. Power Consumption | 16.8W (with USB3.0 Connected), 11.8W (without USB3.0 Connected) |
| PERFORMANCE | |
| GRE | Unencrypted: 624.2Mbps |
| Encrypted: 301.5Mbps | |
| WireGuard VPN | 393.5Mbps |
| Concurrent Session | 150,000 |
| New Sessions / Second | 5,100 |
| NAT (Static IP) | 937.2Mbps / 936.1Mbps |
| NAT(DHCP) | 945.8Mbps / 940.6Mbps |
| NAT(PPPoE) | 942.9Mbps / 942.9Mbps |
| NAT (L2TP) | 837.4Mbps / 881.5Mbps |
| NAT (PPTP) | 803Mbps / 910.5Mbps |
| IPsec VPN Throughput | ESP-SHA1-AES256: 646.9Mbps |
| ESP-SHA256-AES256: 642.8Mbps | |
| ESP-SHA384-AES256: 648.9Mbps | |
| ESP-SHA512-AES256: 658.4Mbps | |
| OpenVPN | 129.3Mbps |
| L2TP VPN Throughput | Unencrypted: 1,034Mbps |
| Encrypted: 570Mbps | |
| PPTP VPN Throughput | Unencrypted: 1,165Mbps |
| Encrypted: 209Mbps | |
| SSL VPN Throughput | 126.7Mbps |
| 66 Byte Packet Forwarding Rate | 1,453,489pps / 1,453,488pps |
| 1,518 Byte Packet Forwarding Rate | 81,274pps / 91,275pps |
| WIRELESS FEATURES | |
| Advanced Features | Seamless Roaming |
| Mesh (with EAP That Supports Mesh) | |
| OFDMA | |
| Beamforming | |
| MU-MIMO | |
| Wireless Encryption: WPA/WPA2/WPA3 Personal, WPA/WPA2/WPA3 Enterprise | |
| Guest Network | Supported |
| BASIC FUNCTIONS | |
| WAN Connection Type | Static IP |
| Dynamic IP | |
| PPPoE (Supports MRU Configuration) | |
| PPTP | |
| L2TP | |
| MAC Clone | Modify WAN Address |
| DHCP | DHCP Server |
| DHCPv6 PD Server (Only in Standalone Mode) | |
| DHCP Options Customisation | |
| DHCP Address Reservation | |
| Multi-IP Interfaces | |
| Multi-Net DHCP | |
| IPv6 | Static IP / SLAAC / DHCPv6 / PPPoE / 6to4 Tunnel / Passthrough / Non-Address Mode |
| VLAN | 802.1Q VLAN |
| IPTV | IGMP v2/v3 Proxy, Custom Mode, Bridge Mode |
| ADVANCED FEATURES | |
| Access Control | IP / Port / Protocol / Domain Name Filtering |
| Advanced Routing | Static Routing |
| Policy Routing | |
| RIP | |
| OSPF | |
| Bandwidth Control | IP-Based Bandwidth Control |
| Load Balance | Intelligent Load Balance |
| Application Optimised Routing | |
| Link Backup (Timing, Failover) | |
| Online Detection | |
| NAT | One-to-One NAT |
| Multi-Net NAT | |
| Port Forwarding | |
| Port Triggering | |
| NAT-DMZ | |
| FTP / H.323 / SIP / IPSec / PPTP ALG | |
| UPnP | |
| Session Limit | IP-Based Session Limit |
| VPN | |
| SD-WAN | Yes (Only in Controller Mode) |
| SSL VPN | 50× Tunnels |
| IPsec VPN | 100× IPSec VPN Tunnels |
| LAN-to-LAN, Client-to-LAN | |
| Main, Aggressive Negotiation Mode | |
| DES, 3DES, AES128, AES192, AES256 Encryption Algorithm | |
| IPsec Failover | |
| IKE v1/v2 | |
| MD5, SHA1, SHA2-384 and SHA2-512 Authentication Algorithm | |
| NAT Traversal (NAT-T) | |
| Dead Peer Detection (DPD) | |
| Perfect Forward Secrecy (PFS) | |
| PPTP VPN | PPTP VPN Server |
| PPTP VPN Client (10×) | |
| 50× Tunnels | |
| PPTP with MPPE Encryption | |
| L2TP VPN | L2TP VPN Server |
| L2TP VPN Client (10×) | |
| 50× Tunnels | |
| L2TP over IPSec | |
| OpenVPN | OpenVPN Server |
| OpenVPN Client (5×) | |
| 55× OpenVPN Tunnels | |
| "Certificate plus Account" Mode | |
| Full-Mode | |
| WireGuard VPN | 20× Tunnels |
| AUTHENTICATION | |
| Web Authentication | No Authentication |
| Simple Password | |
| Hotspot (Local User / Voucher / SMS / Radius) | |
| External Radius Sever | |
| External Portal Sever | |
| LDAP | |
| MANAGEMENT FEATURES | |
| Omada App | Yes |
| Centralised Management | Omada Cloud-Based Controller |
| Omada Hardware Controller (OC300) | |
| Omada Hardware Controller (OC200) | |
| Omada Software Controller | |
| Cloud Access | Yes |
| Service | Dynamic DNS (Dyndns, No-IP, Peanuthull, Comexe, DDNS Customisation) |
| Maintenance | Web Management Interface |
| Remote Management | |
| Export and Import Configuration | |
| SNMP v1/v2c/v3 | |
| Diagnostics (Ping and Traceroute) | |
| NTP Synchronise | |
| Port Mirroring | |
| CLI (Only in Standalone Mode) | |
| Syslog Support | |
| Zero-Touch Provisioning | Yes. Require the Use of Omada Cloud-Based Controller. |
| Management Features | Automatic Device Discovery |
| Intelligent Network Monitoring | |
| Abnormal Event Warnings | |
| Unified Configuration | |
| Reboot Schedule | |
| Captive Portal Configuration | |
| OTHERS | |
| Certification | CE, FCC, RoHS |
| Package Contents | ER706W |
| Power Adapter | |
| Quick Installation Guide | |
| System Requirements | Microsoft Windows 98SE, NT, 2000, XP, Vista or Windows 7/8/8.1/10/11 |
| MAC OS, NetWare, UNIX or Linux | |
| Environment | Operating Temperature: 0~40°C |
| Storage Temperature: -40~70°C | |
| Operating Humidity: 10~90% Non-Condensing | |
| Storage Humidity: 5~90% Non-Condensing | |
